Rototilt RC3
or 4 interest-free installments by Afterpay. More Info
Rototilt® RC3 has been developed for compact excavators weighing between 6-12 tonnes. Despite its low weight, the RC3 can withstand a breakout torque of up to 85 kNm and a working pressure of up to 25 MPa. The SecureLock™ safety lock is always included as standard.
Description
Description
Technical specification
| Machine weight, min-max | 6000 – 12000 kg |
|---|---|
| Weight (from) | 310 kg |
| Bucket width, max | 1500 mm |
| Breakout force, max | 81 kN |
| Breakout torque, max | 85 kNm |
| Tilt angle (2x) | 40 ° |
| Rotation speed (1 revolution in) | 7.0 s at 50 l/min |
| Working pressure | 25 MPa |
| Number of lubrication points | 5 |
|---|---|
| Rotation torque | 7600 Nm |
| Dimension A, Width | 646 mm |
| Dimension B, Installation height total | 936 mm |
| Dimension C, Length | 679 mm |
| Dimension D, Installation height | 504 mm |
